High Voltage Insulation Tester BE3125
This professional Voltage Insulation tester is designed with voltage overload protection and high voltage indicator to safely measure voltage in 50V, 100V, 250V, 500V,1000V,2500V and 5000V. It has a dual display when measuring under Insulation Resistance, it simultaneously show the selected voltage range and insulation resistance measured reading. These measurements can be use to evaluate insulation integrity. This troubleshooting tool is a quality control measure at the time a piece of electrical equipment is produced and an installation requirement to help ensure specifications are met and to verify proper hookup. It also use as a periodic preventive maintenance task
Feature
* Professional Digital Voltage Insulation Tester
* Auto discharge function, operate more safely
* LCD backlight
* Auto power off, makes battery life longer
* Simultaneous dual display (only when measuring Insulation Resistance):
selected Voltage range and Insulation Resistance measured reading
* Over-range indication for Insulation resitance & Voltage
* Over load protection
* Low battery indication, preserve accuracy and preciseness of every reading
* Design in accordance with IEC 61010-1 CAT.III 600V Type 2 and IEC 61010-031 international standards
* With CE marking, meets EU safety, health and environmental requirements
* Includes heavy-duty test leads and batteries
Spesification
* Rated Voltage:500V/1000V/2500V/5000V
* TestingRange:500V:0.0~999MΩ;1000V:0.0~1.99GΩ?2500V:0.0~99.9GΩ;5000V:0.0~1000GΩ
* Accuracy:±5%rdg±5%dgt
* DC/AC Testing:30~600V
* Resolution:1.0V
* Overload Protection:AC 1200V/10 sec
* Withstand Voltage:AC8320V/5 sec
* Insulation Resistance:1000MΩ/DC1000V
* Line Probe
* USB Trasmission
* Short Circuit Current:1.4mA
* Polarization Index
* DAR
* Operation Voltage:12V
* Power:8x1.5V LR14 Battery
* Unit size:153x96x220mm
* Standard Quantity Per Carton:3PCS
* Standard Carton Size:44.5x33.0x28.5CM
* Standard Carton Gross Weight:7.2KG
To make sure that there is no person on the measured equipement;
The wines must be placed apart not messed up togeter;
Discharge the equipment that is of large,capacitance,after test;
Calibrate the accuracy regularly
