High Precision Loop Calibrator MS7207



This Loop Calibrator is designed with output current, simulate output current,output voltage function, it is used for detecting and debugging automatic control equipment in industry scene.


Feature

* Fast measure, only press button can be used to calibrate immediately
* Display conveniently mA reading and % reading, reading easy.
* High Accuracy of mA reach 0.02%
* High resolution 1uA to simulation and measuring
* Button control at 25% stepping ramp , be good for linearity detection
* 0~100% span check function can be used to check the zero or span spacing of a transmitter
* Slow ramp, fast ramp and stepping function, offer continuous and smooth output to measure loop and valve slide
* supply 24V loop power to the transmitter and read the loop current value simultaneously
* measure DCV top to 28V DCV
* 0-20mA or 4-20mA default start mode
* Precent display
* 250W HART resistance
* Signal Adjustmode: Special(quick induction)
* Backlight


Spesification

Function

   Range

Resolution

Accuracy

DC Volts Input

0~28.000V

1mV (mV)

±(0.05%o +4)

DC mA Input

0~24.000mA

1uA

±(0.05% +4)

Source output mA or Simulate output mA Loop power output mA

0 ~20.000mA
or 4~20mA

   1uA

±(0.05% +2)

Loop Power

≥24V, ≤30V











General Specifications:

The voltage between any two terminals, or between any terminal and earth ground

max 30V

Storage temperature

-40?-60?

Operation temperature

-10?-55?

Operation elevation

max 2000m in height

Temperature coefficient

0.005%´ range /? (-10?—18? or 28?—55?)

Relative humidity

95% up to 30?, 75% up to 40?,
45% up to 50?, 35% up to 55?.

Vibration

random sampling 2 grams, 5-500Hz

Impact

1m free drop test

Size

195(L)x92(W)x55(H) mm

Weight

About 400g, (including the rubber cover).

Conformity to safety standards

Meet the standard of IEC 61010-1-95 CAT III, 300V;
Meet the standard of EN61010-1 EN61326.

Battery

1x9 V alkaline battery
